Lab Gruppen LUCIA 120/2M

Lab Gruppen LUCIA 120/2M

Regular price Dhs.0.00 AED
Regular price Dhs.0.00 AED Sale price Dhs.0.00 AED
Sale Sold out

For Wholesale Enquiries Please Contact Us On WhatsApp

This is our wholesale website, for retail purcahses please visit our retail website MusicMajlis.co

KEY FEATURES

  • Integrated Mix Matrix and DSP (LUCIA ’M’ models only): The versatile 4 × 4 Mix Matrix and comprehensive DSP features including Automatic Dynamic Loudness Contouring (ADLC™), featured on the LUCIA240/2M and 120/2M eliminate the need for external mixers and processors in many applications, saving time and money. A software wizard facilitates fast setup, while the advanced editor allows offline configuration of common presets that can be quickly downloaded to multiple units via USB.
  • Green credentials: All LUCIA models are EnergyStar® qualified, making them an ideal choice for installation in projects seeking energy-efficient certifications. The amplifier automatically enters standby mode after 20 minutes of no signal input, consuming less than 1 watt.Automatic power-up requires less than two seconds of input signal presence.
  • 2-Channel LUCIA: Extremely compact and versatile Energy Star qualified Class D amplifier platform. Combining innovative low-impedance electronics with cutting-edge processing from the world of high-end broadcast audio, LUCIA delivers consistently great sound at any listening level.
  • LUCIA provides industry-renowned amplification, innovative auto-configuring DSP, flexible input and routing control (M-models only) in one quiet-running device. It does all the hard work, providing better sounding results ‘out-of-the-box’, preventing audible clipping – even when subject to demanding operating conditions (eg. overdriven). LUCIA always sounds great.
  • Max. output power across range of loads – 2 × 60 W(LUCIA 120/2) or 2 × 120 W (LUCIA 240/2) into 8, 4 or 2 ohms
  • Comprehensive DSP features - multiband compressor, look ahead limiter
  • Default preset mode – Works out of the box for common applications with no configuration
  • GPIO – Remote control (eg. Wall panel) for channel switching, level – integration with paging systems
  • Compact form factor – Half-rack, 1U chassis and supplied bracket for discreet on-wall mounting (eg. behind display screens)
  • Efficient patented Class D amplifier
  • Auto Load Sense™ – Proprietary auto-set VPL™ (Voltage Peak Limiter) for optimum performance with connected load
  • Fail-safe operation – Comprehensive short circuit, thermal, and under-voltage protection
  • Balanced and unbalanced (RCA) inputs – Connects to any input source
  • Universal power supply – Operates at 100 - 240V AC (50 or 60 Hz)
  • ENERGY STAR® 3.0 compliant – Conforms to green building standards
  • Auto standby and wake-up – Standby power consumption less than 1 W
  • Intelligent fan control – Silent operation in idle and at lower output levels
  • Sturdy metal chassis – Protection for long-term durability
  • CE, CSA, CCC and PSE approvals: – Conforms to building codes worldwide



DESCRIPTION

LUCIA 120/2M Incorporates Ease of Install with 2 X 60 W of Decentralized Power in a Compact, Energy Star Compliant Amplifier.

Lab Gruppen’s innovative LUCIA (Localized Utility Compact Intelligent Amplification) brings superior audio performance and extraordinary flexibility to a decentralized approach in AV systems design. Power, processing, control and I/O are conveniently placed exactly where they are needed. In many AV applications requiring consistently outstanding performance, LUCIA offers a logical, cost-efficient and scalable solution that often eliminates the complications and added expense of a centralized equipment room. LUCIA amplifiers incorporate a digital, firmware-controlled front end coupled to a robust, durable and highly efficient Lab Gruppen output stage, all of which make LUCIA the best-sounding and most reliable compact amplifier in its category.



SPECIFICATIONS

Number of amplifier channels:

2

Max total output all channels driven:

120W

Max output current per channel:

5.5 arms

Input impedance:

10 kOhm

Frequency Response:

5 Hz - 22 kHz

Input connectors (ch. 1 & 2):

Unbalanced RCA type

Dimensions:

W: 216 mm (8.5”), H: 44 mm (1 U), D: 280 mm (11”)

Weight:

1.9 kg (4.2 lbs)
