Klark Teknik 2A-KT Classic Leveling Amplifier
Klark Teknik 2A-KT Classic Leveling Amplifier
Couldn't load pickup availability
For Wholesale Enquiries Please Contact Us On WhatsApp
This is our wholesale website, for retail purcahses please visit our retail website MusicMajlis.co
Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
KEY FEATURES-
Classic tube compressor/leveling amplifier modeled after the iconic Teletronix LA-2A*
-
Completely discrete signal path
-
Premium selection 12AX7, 12BH7 and EL84 tubes
-
Lag-free optical attenuator based on original electroluminescent technology
-
Custom-built Midas input and output transformers
-
Frequency Response: 10 Hz to 20 kHz, +/- 1 dB
-
Gain Limiting: 0 to 30 dB
-
Ultra-fast attack time: 10 milliseconds
-
Release time: 50 milliseconds to 5 seconds
-
Adjustable stereo-link connection
-
Variable pre-emphasis for digital audio recording and broadcasting transmission
-
Vintage-style meter features gain reduction and output
-
Transformer balanced inputs and outputs on Neutrik* XLR connectors
-
Rugged 2U rackmount chassis for durability in portable applications
-
Auto-ranging universal switch-mode power supply
DESCRIPTION
If ever there is an official “Audio Technology Hall of Fame”, it will definitely include a shrine to the iconic Teletronix LA-2A*. We pay homage to this audio-processing pioneer that has graced so many recordings, with our 2A-KT Classic Leveling Amplifier. And while vintage Teletronix LA-2As are extremely rare and expensive, the 2A-KT is amazingly affordable – and designed for the 21st Century. Mastering quality compression and limiting, at a price point that makes the 2A-KT equally at home in your studio – and your live rack!
SPECIFICATIONS
|
Audio Input |
|
|
Type |
XLR, 1/4" TRS, transformer balanced |
|
Impedance |
600 Ω, balanced and unbalanced |
|
Maximum input level |
+20 dBu, balanced and unbalanced |
|
CMRR at 1 kHz |
Typically -80 dB |
|
Audio Output |
|
|
Type |
XLR, 1/4" TRS, transformer balanced |
|
Impedance |
70 Ω, balanced and unbalanced |
|
Maximum output level |
+18 dBu, balanced and unbalanced |
|
System Specifications |
|
|
Frequency response |
10 Hz to 20 kHz, ±1 dB |
|
Noise at unity gain |
-87 dBu, unweighted, 20 Hz to 20 kHz |
|
THD at unity gain 0 dBu input level |
Typically <0.1% 20 Hz to 20 kHz |
|
Compressor |
|
|
Attack time |
Typically 10 ms |
|
Release time |
Typically 50 ms for 50% release, up to 5 s for full release |
|
Maximum output gain |
+30 dB |
|
Maximum peak reduction |
-30 dB |
|
Tube types |
2x 12AX7, 1x 12BH7, 1x EL84 |
|
Meter settings |
Gain Reduction, +4 output, +10 output |
|
Power Supply |
|
|
Mains voltage |
100 – 240 V~, 50/60 Hz |
|
Power consumption |
30 W |
|
Fuse |
T1AH 250 V |
|
Mains connection |
Standard IEC receptacle |
|
Physical |
|
|
Dimensions (HxWxD) |
88 x 483 x 158 mm (3.5 x 1.9 x 6.2") |
|
Weight |
2.9 kg (6.4 lbs) |
