2 state-of-the-art, Midas mic preamplifiers with +48 V phantom power
Audiophile 192 kHz 2x2 USB audio interface, perfect for computer-based studios
True VCA control for extremely precise level control and stereo tracking
4 inputs with level controls plus additional USB monitoring from your DAW
2 independent and adjustable monitor outputs to connect up to 2 sets of studio monitors
DESCRIPTION
Midas Mic Preamp – Legend Inside! Did you know that Midas is one of the most recognized brands used by audio professionals around the world? Now you can get the gear the pros use! STUDIO L comes with two state-of-the-art Midas microphone preamplifiers with +48 V phantom power, ultra-low noise, high gain and audiophile quality.
The STUDIO L is the ideal solution for home or professional studios, or as part of a larger setup. Premium, ultra-low noise components and high headroom lets your music shine at its best – this is especially true for one of the most critical sources: Vocals!
Crystal Clear Signal Path at 192 kHz The STUDIO L is more than just a monitor controller – we added one of the best USB audio interfaces with the highest possible resolution and lowest latency. Full 192 kHz sampling rate at a clear 24-bit resolution will make you smile listening to the crisp and astonishing sound you’ll get.
VCA-Control – Not Just a Volume Knob Unlike the typical and inexpensive potentiometers used by our competitors, the STUDIO L utilizes high-end Voltage Controlled Amplifier (VCA) technology. While conventional monitor controllers directly pass the signal through the volume potentiometer, the STUDIO L controls a separate high-precision amplifier circuit that drives the volume change. For perfect stereo and phase coherency, precision level adjustment, accurate sound and no quality degradation over time.
The All-In Device The STUDIO L integrates seamlessly into your existing setup. You can even make it the center piece of your studio. Thanks to the built-in audio interface and Midas microphone pre-amps it becomes an all-in-one recording solution, just add your computer and you’re ready to go.
More Monitor Options Today’s recordings have to sound great everywhere: in the car, at home, on your cell phone, soundbar, Bluetooth speakers and in the club – so experiencing your mix through as many speaker systems as possible is more essential than ever. High Quality, Best Value The STUDIO L to provide many years of super-clean, high-fidelity performance in the most critical listening environment – yours! Built from the highest-grade components, STUDIO L is the perfect way to add a lot more convenience into your current studio setup.
SPECIFICATIONS
Inputs
Inputs
4
Preamps
2 x Midas designed
Type
2 x XLR / TRS combo connector (mic/line)
Impedance
Mic: 3 kΩ / Line: 1 MΩ
Line inputs
2 x 1/4" TRS, balanced or unbalanced, +4/-10 dB 1 x 1/8" TRS stereo (input 3/4)
Maximum input level
+22 dBu
Outputs
Outputs
3 stereo
Line outputs
6 x 1/4" TRS, balanced or unbalanced
Headphone outputs
2 x 1/4" TRS stereo
Maximum output level
+22 dBu
USB
Type
Class compliant USB 2.0, type B
Supported operating systems
Windows 10/ Mac OS X 10.14 or higher
Audio
2 in / 2 out
Converter resolution
24-bit
Supported sample rate
44.1, 48, 88.2, 96, 192 kHz
Talkback Section
Output level
-∞ to +10 dB
Talback level
-∞ to max
Takback destination
cue
Controls
Phantom power
+48 V (inputs 1/2)
Volume
High-precision stereo tracking VCA volume control 0 - 100%
Playback controls
Mono, Mute, Dim
Monitor select
A, B
Input 1/2
48 V on/off, Stereo on/off, 1/2 (channel select) on/off
