Behringer RD-8 MKII Classic Analog Drum Machine
Behringer RD-8 MKII Classic Analog Drum Machine
Couldn't load pickup availability
For Wholesale Enquiries Please Contact Us On WhatsApp
This is our wholesale website, for retail purcahses please visit our retail website MusicMajlis.co
Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
KEY FEATURES
-
Amazing drum machine with authentic analog sound engine to create classic sound performance
-
16 original drum sounds with additional parameters and global accent capability
-
Reproduction of legendary 662 OTA chip for ultimate sound authenticity
-
Powerful 64-step drum sequencer supports poly-meter, step-repeat, note-repeat, real-time triggering, track-mute and track-solo
-
11 independent analog outputs for external processing or recording your rhythms as multi-track audio
-
Integrated FX bus features Wave Designer and dual-mode Analog Filter with per voice assignment
-
Live recording, editing and playback of analog filter cutoff via automation
-
Storage of up to 16 songs and 256 patterns, all of which can be imported/exported during playback for unlimited songs and patterns
-
Pattern Mode allows arrangement of patterns into full songs and setting number of repeats per song part
-
Song Mode allows chaining songs together for live sets and expanded compositions
-
Unique Auto Scroll feature enables improvisation in all modes
-
Comprehensive MIDI In/Out/Thru plus USB implementation for synchronization and connection to external devices
-
Sync options include USB, MIDI, Clock and Internal for maximum versatility
-
Encoder for editing parameters such as Tempo, Swing, Probability, Flam and Random
-
High-visibility LED display for easy editing of program parameters
-
Powerful headphone and main outputs
DESCRIPTION
The RD-8 MKII provides all the tools you need to become a master beat-maker, including: 16-drum sounds; a 64-step sequencer; Wave Designer and dual-mode filter – for a full-fledged drum machine that’ll shake the house! Whether you’re new to drum programming or a seasoned pro looking to upgrade your setup, the RD-8 MKII has everything you need to step up to the big time.
SPECIFICATIONS
Voices
| Number of sounds |
16 |
| Type |
Analog |
| Number of simultaneous voices |
11 (12 including global accent) |
| Sound controls | |
| Accent |
Level |
| Bass drum |
Level, tone, decay, tuning |
| Snare drum |
Level, tone, snappy |
| Low, mid, hi conga / low, mid, hi tom |
Level, tuning, voice selection |
| Claves / rim shot |
Level, voice selection |
| Maracas / hand clap |
Level, offset, voice selection |
| Cow bell |
Level |
| Cymbal |
Level, tone, decay |
| Open hat |
Level, tone, decay |
| Closed hat |
Level, tone |
| Select buttons |
16 Voice select buttons |
Connectivity
| Outputs | |
| Phones |
1 x ¼" TRS, stereo, 8 Ω impedance |
| Mono |
1 x ¼" TRS, servo-balanced |
| Voice out |
11 x ¼" TS, unbalanced |
| MIDI In, Out & Thru |
3 x 5-pin DIN |
| Trigger outs |
3 x +5 V, 1 ms pulse |
| Clock in / out |
2 x 1/8" TS |
| USB |
Class compliant USB 2.0, type B |
| Supported operating systems |
Windows 7 or higher Mac OS X 10.6.8 or higher |
| Volume controls |
Master, phones |
| Return (Input) |
1 x ¼" TRS, balanced |
Wave Designer
| Bus |
11 voices, independently assignable |
| Controls | |
| Attack |
-15 to +15 dB, adjustable |
| Sustain |
-24 to +24 dB, adjustable |
| Send button |
On/off, switchable |
| Sig LED |
Red |
Analog Filter
| Type |
State variable, 12 dB slope |
| Cutoff |
10 Hz - 15 kHz, adjustable |
| Resonance |
0 - 10, adjustable |
| HPF button |
LPF / HPF mode, switchable |
| On button |
On / off, switchable |
Sync Section
| Mode selector |
Internal / MIDI / USB / Clock, selectable |
Sequencer Section
| Edit buttons |
Save, copy, erase and dump |
| Mode buttons |
Song, pattern and step |
| Control |
Encoder for data editing |
| Playback controls |
Tap / hold, record, stop, play / pause |
| Data mode |
Tempo / swing / prob / flam, selectable |
| Auto scroll |
On / off, rewind, length (16 / 32 / 48 / 64, selectable), fast forward |
| Trigger |
On / off, repeat division (1 / 2 / 4 / 8, selectable), step repeat, note repeat |
| Track |
Mute / solo, selectable |
| Step buttons |
16 step enter buttons |
Settings
| Settings |
Enter settings mode, use step buttons to select operation. |
Autofill
| Autofill |
Enter autofill selection mode |
Songs / Storage
| Song mode |
Chain any of the 16 songs together for full sets |
Pattern / Storage
| Capacity |
16 songs, 16 patterns each |
| Pattern mode |
Up to 99 iterations per pattern/part |
| Steps |
64 steps |
Power Supply
| External power adapter |
18 V DC, 1000 mA |
| Power consumption |
15 W typical |
Environmental
| Operating temperature range |
5°C to 40°C (41°F to 104°F) |
Physical
| Dimensions (H x W x D) |
77 x 498 x 265 mm (3.0 x 19.6 x 10.4") |
| Weight |
3.0 kg (6.6 lbs) |
