Behringer EURORACK RACK 19" Desktop/Rack-Mount Kit with Power Supply for 84 HP Eurorack

Behringer EURORACK RACK 19" Desktop/Rack-Mount Kit with Power Supply for 84 HP Eurorack

Dhs.441.00 AED
Dhs.0.00 AED Dhs.441.00 AED
Sale Sold out

For Wholesale Enquiries Please Contact Us On WhatsApp

This is our wholesale website, for retail purcahses please visit our retail website MusicMajlis.co

Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information

KEY FEATURES

  • Desktop/rack-mount kit converts 19" rack into 84 HP Eurorack chassis

  • Ideal for Behringer synthesizers and other Eurorack equipment

  • Rugged aluminum chassis accommodates 84 HP rack-mounted and desktop setups

  • Compact 4 HP power supply with two flying bus boards included (+12 V@1 A, -12 V@1 A, +5 V@0.5 A)

  • Easy positioning of your modules with the included 52 sliding nuts


DESCRIPTION

The EURORACK RACK is ideal for any Behringer Eurorack-style synthesizer or equipment. This desktop/rack-mount kit converts a 19” rack into an 84 HP Eurorack chassis. A compact 4 HP power supply with two flying bus boards are included together with a 3A universal power adapter. 52 sliding nuts allow you to easily position your modules so you can freely position your synth wherever you need it.

SPECIFICATIONS

Connectivity of Power Supply Module

Front panel

DC Power inputPower switch (toggle)

Power Requirements

External power adaptor (use only the supplied adapter)

13 VDC, 3 A

Power consumption

35 W maximum

PCB Connectors

Quantity 2, box header, straight, 16 pin, 2 rows, pitch 2.54 mm

Power outputs and pin outs

+5 VDC @ 0.5 A, pins 11, 12

-12 VDC @ 1 A, pins 1, 2

+12 VDC @ 1 A, pins 9, 10

Ground, pins 3, 4, 5, 6, 7, 8

Environmental

Operating temperature range

5°C – 40°C (41°F – 104°F)

Environment

Dry, indoor use only

Physical

Dimensions (H x W x D)

482.6 x 132.5 x 89.5 mm (19.0 x 5.2 x 3.5")

Module width

1 bay of 84 HP (fully useable width), rack mountable

Maximum depth of module that can be inserted *

39 mm (1.54")

Dimensions of power supply module only

129 x 20 x 52 mm (5.08 x 0.79 x 2.05") (4HP)

Weight including power supply module

0.55 kg (1.21 lbs)

Weight of power supply module only

0.056 kg (0.124 lbs)

Accessories

Included

Power adapter
