Behringer
Behringer CONTROL2USB
Behringer CONTROL2USB
Couldn't load pickup availability
For Wholesale Enquiries Please Contact Us On WhatsApp
This is our wholesale website, for retail purcahses please visit our retail website MusicMajlis.co
Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
Take control of your studio with the Behringer CONTROL2USB. This ultra-low noise, high headroom center combines master volume control, source selection, monitor switching, and a talkback box. With four stereo inputs, a monitor mix input, built-in talkback microphone, and a large volume knob for precise adjustments, you have all the communication and control you need. The CONTROL2USB also features a built-in USB audio interface and a phono preamp for turntables, giving you complete studio command.
FEATURES:
-
Premium, ultra-low noise and high headroom studio control and communication center
-
All-in-one Master Volume controller, Source selector, Monitor switcher and Talkback box
-
4 stereo inputs with independent level controls plus additional Monitor Mix input for your DAW
-
3 independent and adjustable Monitor outputs to connect up to 3 sets of studio monitors
-
Built-in Talkback microphone with Level control for direct communication with musicians
-
Large Volume knob with true VCA control for extremely precise level adjustments
-
Built-in stereo USB Audio Interface, perfect for computer-based studios
-
Premium-quality phono preamp for direct turntable connection
-
2 powerful headphone amplifiers with separate volume controls
-
Convenient Mono, Mute and Dim functions right at your fingertips
-
High-precision dual 12-segment LED meters with input/output source switch
-
"Planet Earth" switching power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior transient response plus low power consumption for energy savings
-
3-Year Warranty Program*
-
Designed and engineered in Germany
SPECIFICATIONS:
|
Frequency Response |
|
|
Line-level inputs and outputs |
|
|
1/4" jack, balanced or unbalanced |
10 Hz to 40 kHz (+0 dB / -1 dB) |
|
Phono input |
20 Hz to 20 kHz (±1 dB) |
|
Distortion (THD & IMD) |
|
|
Line-level inputs to line-level outputs (unity gain) |
<0.02 %, 20 Hz to 20 kHz @ +4 dBu |
|
Phono input |
<0.10 %, 20 Hz to 20 kHz @ +4 dBu |
|
Noise Floor |
|
|
Unity gain with Input 1, 2 and 3 assigned |
-86 dBu, 20 Hz to 20 kHz |
|
Monitor A, B and C outputs, studio output, DAW, 2-track A & B outputs |
-90 dBu, 20 Hz to 20 kHz |
|
Phono input |
-75 dBu, 20 Hz to 20 kHz |
|
Equivalent input noise (E.I.N.) |
-119 dBu, 20 Hz to 20 kHz |
|
Dynamic Range |
|
|
Line inputs |
107 dB |
|
Phono input |
88 dB |
|
Crosstalk |
|
|
Adjacent inputs |
95 dB @ 1 kHz |
|
Left to right / right to left |
85 dB @ 1 kHz |
|
Muted / level off |
95 dB @ 1 kHz |
|
Control Range |
|
|
Input level |
±10 dB |
|
Output level |
-12 dB to 0 dB |
|
Dim switch |
0 dB / -20 dB |
|
Rated Input Voltage |
|
|
Line inputs (+4 dB level setting) |
+4 dBu / +30 dBu (nominal / maximum) |
|
Line inputs (-10 dB level setting) |
-10 dBu / +15 dBu (nominal / maximum) |
|
Phono input @ 1 kHz, nominal gain |
5 mV / 90 mV (nominal / maximum) |
|
Rated Output Voltage |
|
|
All line-level outputs (+4 dB level setting) |
+4 dBu / +21 dBu (nominal / maximum) |
|
All line-level outputs (-10 dB level setting) |
-10 dBu / +8 dBu (nominal / maximum) |
|
Maximum Voltage Gain |
|
|
Input 1, 2 and 3 to: |
|
|
Monitor A, B and C outputs |
+32 dB |
|
DAW, 2-track A & B, and phones (rear) outputs |
+22 dB |
|
Studio output |
32 dB |
|
Phones 1 & 2 outputs |
32 dB (output loaded @ 100 kΩ) |
|
Monitor mix input to: |
|
|
Phones (rear) outputs |
12 dB |
|
Studio output |
22 dB |
|
Phones 1 & 2 outputs |
22 dB (output loaded @ 100 kΩ) |
|
Phono input @ 1 kHz to: |
|
|
Monitor A, B and C outputs |
65 dB |
|
DAW, 2-track A & B, and phones (rear) outputs |
55 dB |
|
Studio output |
66 dB |
|
Phones 1 & 2 outputs |
66 dB (output loaded @ 100 kΩ) |
|
Input Impedance |
|
|
Line input |
20 kΩ balanced / 14 kΩ unbalanced |
|
Phono input |
40 kΩ |
|
Output Impedance |
|
|
Line output |
200 Ω balanced / 100 Ω unbalanced |
|
Headphone output |
50 Ω |
|
Input/Output VU Meters |
|
|
12-segment LED |
CLIP, +10, +7, +4, +2, 0, -2, -4, -7, -10, -20, -30 dB |
|
Talkback Section |
|
|
Automatic gain control (AGC) |
Yes |
|
Nominal output level |
+4 dBu (+4 dB output level setting) |
|
Output level range |
-∞ to +10 dB |
|
Power Supply / Voltage (Fuses) |
|
|
Mains voltage |
100-240 V~, 50/60 Hz |
|
Fuse |
T 1AH 250 V |
|
Power consumption |
15 W |
|
Mains connection |
Standard IEC receptacle |
|
USB |
|
|
Audio |
Stereo in / out |
|
Connector |
Type B |
|
Sample rate |
44.1 / 48 kHz |
|
Dimensions/Weight |
|
|
Dimensions (H x W x D) |
87 x 389 x 198 mm (3.4 x 15.3 x 7.8") |
|
Weight |
2.4 kg (5.3 lbs) |
HOW IT WORKS:
The BEHRINGER CONTROL2USB is an all-in-one control center that offers Master Volume, Source selection, Monitor switching, and Talkback control. It features 4 stereo inputs with independent level controls plus an additional Monitor Mix input for your DAW. The built-in Talkback mic allows you to communicate directly with musicians in the studio. The large Volume knob offers precise level adjustments for your recordings and mixes. The CONTROL2USB also features a built-in stereo USB Audio Interface and a premium-quality phono preamp for direct turntable connection.PRODUCT FAQ:
Q: Does the CONTROL2USB offer Talkback control?Share
