Ahuja UBA-500M 500 Watts DJ & PA Power Amplifier
Ahuja UBA-500M 500 Watts DJ & PA Power Amplifier
Couldn't load pickup availability
For Wholesale Enquiries Please Contact Us On WhatsApp
This is our wholesale website, for retail purcahses please visit our retail website MusicMajlis.co
- Designed for use in a wide variety of PA applications and DJ performances.
- UBA-500M is a 500 Watts amplifier which can be connected to various input sources like a Microphone, PA Mixer, DJ Mixer, CD Player, Cassette Player, Keyboard etc.
- The amplifier includes an built-in 5 Band Graphic Equalizer with tone ON/OFF switch which enables precise and accurate tonal setting of the programme.
Specifications:
|
Power Output |
650W RMS Max., 500W RMS at 10%THD, 475W RMS at 5% THD 450W RMS at 2% THD |
|
Output Regulation |
≤ 2dB, no load to full load at 1kHz |
|
Input Channels |
1 × Mic 1mV / 4.7kΩ, 1 × Aux 100mV / 470kΩ, 1 × Aux 250mV / 20kΩ, 1 × CD 250mV / 20kΩ, 1 × Line 1V / 10kΩ |
|
Frequency Response |
50Hz–18,000Hz ±3dB |
|
Signal to Noise Ratio |
60dB |
|
Tone Controls |
Bass (100Hz) : ± 8dB, Lo-Mid (315Hz) : ± 8dB, Mid (1kHz) : ± 8dB, Hi-Mid (3.1kHz) : ± 8dB, Treble (10kHz) : ± 8dB |
|
Line Output |
1V/1kΩ |
|
Speaker Output |
2Ω, 4Ω & 8Ω |
|
Power Supply |
AC: 220-240V 50/60Hz |
|
Protections |
2 × 20 Amp fuse in ± DC supply 5 Amp circuit breaker in AC mains, Protected against high AC mains voltage, overload & temperature |
|
Power Consumption |
1000 VA |
|
Dimensions |
W482 × H166 × D435 mm |
|
Weight |
23.5kg |
