Wharfedale Pro DP2200N Power Amplifier 1x9520W @4Ohm with FIR Filter

SKU: DP2200N

Log in to view price Trade pricing — AED / USD

Only 4 left
Low inventory - Hurry up!
Request Bulk Pricing

Ask an AV specialist

Video chat Chat Email +971 50 559 4871

  • Full Specifications

    Note - It is imperative to use the Wharefedale Pro SC48FIR DSP with any Wharfedale Pro WLA Series Line Array. This is part of a system. We recommend contacting our sales team for a full system design.

    KEY FEATURES

    • Huge Class D power in a 1U rack
    • 4 discrete amplification channels
    • Internal DSP and computer control
    • Stable down to 2 Ω. Drive multiple speakers or line array elements
    • FIR filtering with 512 taps
    • 90 V to 260 V AC working voltage
    • Dante ™ connectivity
    • 70 V / 100V compatible models
    • Power Factor Correction

 for increased efficiency


    DESCRIPTION

    TAKE CONTROL

    Harnessing the power of the internal DSP. The supplied editing software gives a practical overview of all system parameters and DSP features within the DP-N amplifier. It is simple to monitor and edit the DP-N remotely.

    REDUNDANCY

    DP series amps get used in ‘mission critical’ environments.  Therefore the ‘auto’ mode has been built in to deliver redundancy capability.

    Set the input to ‘Auto’ and the input will change, should a problem happen with external connections. (Use of an internal delay is advised to compensate for any switch timing and latency issues)

    SPECIFICATIONS

    Output RMS voltage 126.5 V
    Maximum Input Level +21 dBu
    Amp gain 35 dB
    THD+N Typical value:0.05%(10% Rated Power,8 Ω)
    Cross-Talk ≥90 dB(20 Hz-1 KHz,Below Rated Power,8 Ω)
    Frequency Response Typical value:+0,-0.5 dB(10% Rated Power,20 Hz-20 KHz,8 Ω)
    Input Impedance 20 kΩ(Balanced),10 kΩ(Unbalanced)
    Damping Factor ≥1000(20 Hz-200 Hz,8 Ω)
    SNR ≥105 dB (Default Gain, A weighted,20 Hz-20 KHz,8 Ω)
    Main Power 90~260 VAC,50/60 Hz
